產品特色
- 7th gen Intel® Core™ i7/i5/i3 and Celeron® processors (Kaby Lake-U)
- 2 DDR4-2133 SO-DIMM for up to 32GB of memory
- Max. up to 6 lanes of PCI Express
- 3 SATA-600
- 4 USB 3.0 and 8 USB 2.0
- TPM 1.2 supported
- AXView 2.0 intelligent remote management software
產品簡介
The eBOX565-500-FL is designed to support the 6th generation Intel® Core™ i5-6300U or Celeron® 3955U processor with one 260-pin DDR4-2133 SO-DIMM socket with up to 16GB system memory. The eBOX565-500-FL is designed for reliable use in industrial environments with an IP40-rated enclosure, a wide range 9 to 36 VDC power input, a wide temperature ranges from -10°C to 50°C (14°F to 122°F), as well as up to 3G vibration endurance. To fulfill various needs, the palm-sized industrial embedded computer, which measures 141.6 x 106 x 73 mm in size, provides rich I/O connectivity including two HDMI ports, one RS-232/422/485 port, one RS-232 port, four USB 3.0 ports, two Gigabit Ethernet ports, and two SMA type connector openings for antenna. One PCI Express Mini Card slot enables the addition of Wi-Fi, 3G, or LTE wireless cards.
