Fanless & Extended Temperature Embedded Solutions

Introduction l Advantages

Introduction

AXIOMTEK provides a wide array of fanless and extended temperature embedded products from board level products to whole systems (eBOX). To improve the system reliability for extreme temperature environments and to extend the MTBF, AXIOMTEK's embedded solutions have adapted a fanless system by improving the board design and enhancing quality screening during production. AXIOMTEK's fanless & extended temperature embedded solutions supply stable and reliable hardware platform performance and are designed particularly to meet more rigorous industrial applications.

Fanless & Extended Temperature Embedded Systems (eBOX Series)

eBOX830-831-FL
Fanless Embedded System with Intel® Core™2 Duo Processor

Supporting a fanless design, AXIOMTEK's eBOX series can operate without noise and are highly reliable, operating in critical temperature environments from -20°C to +60°C. The eBOX series is suitable for a wide range of industrial applications in the market, such as POS, kiosk, ATM, Thin Servers, diskless workstations, building automation, project screens for department stores and supermarkets, tour bus displays, and much more.

All eBOX systems support CompactFlash™ and 2.5" HDD drive bays, which provide a plentiful range of expansion. To enhance system reliability for critical demands, each eBOX supports Watchdog Timer function which will automatically reset the system to reduce the need for maintenance. Additionally, the eBOX series supports most operating systems, including Windows® CE.NET, Windows® XP Embedded and Embedded Linux.


Model	Description	Extended Temp.
eBOX600-FL	Fanless Embedded System with Intel® Celeron ® M Processor	-10 ~ 50°C (w/ W.T. CF/HDD)
eBOX630-821-FL	Fanless Embedded System with Intel® Pentium® M Processor	0 ~ 50°C (w/ W.T. HDD)
eBOX630-830-FL	Fanless Embedded System with Intel® Core™2 Duo Processor	0 ~ 50°C (w/ W.T. HDD)
eBOX638-FL	Fanless Embedded System with Intel® Pentium® M Processor up to 1.4GHz and PCI-X	-10 ~ 50°C (w/ W.T. CF/HDD)
eBOX646-FL500-4COM	Fanless Embedded System with AMD LX800 500MHz Processor	-10 ~ 50°C (w/ W.T. CF/HDD)
eBOX647-FL	Fanless Embedded System with VIA Processor up to 1.5 GHz	0 ~ 50°C
eBOX738-FL	Fanless Embedded System with Intel® Pentium® M Processor up to 1.4GHz	-20 ~ 50°C (w/ W.T. CF/HDD, AC P/S)
eBOX745-FL500	Fanless Embedded System with AMD LX800 500MHz Processor	-20 ~ 50°C (w/ W.T. CF, AC P/S)
eBOX746A-FL	Fanless Embedded System with VIA Processor up to 1.5GHz	-5 ~ 50°C (w/ W.T. CF/HDD, AC P/S)
eBOX748-FL	Fanless Embedded System with Intel® Pentium® M Processor up to 1.4GHz	-10 ~ 50°C (w/ W.T. CF/HDD, AC P/S)
eBOX830-831-FL	Fanless Embedded System with Intel® Core™2 Duo Processor	0 ~ 45 °C (w/ W.T. HDD)

Integrated with the proper components and passing a rigorous production screenings, AXIOMTEK' s SBC's which are utilized in the eBOX's and are guaranteed to work well in wider temperature range environments, from -25°C to + 70°C . AXIOMTEK's extended temperature embedded boar ds employ low-power core logic computing engines: from AMD LX800, VIA Eden V4/V7, to ULV/LV Intel® Pentium® M/ Celeron® M to Intel® Core™2 Duo for x86 architecture. AXIOMTEK has the right tools for any application. Cooling fans usually have an MTBF of approximately 20,000 hours, which is not acceptable for most applications. AXIOMTEK's SBC's provide the answer: an onboard low power consumption CPU that eliminates fan usage for better system reliability.

SBC84620
AMD LX Embedded SBC with Dual Fast Ethernet, 4 COM and USB 2.0

Available SBC Models:


Model	Description	Normal	Extended
SBC84810	Intel® Celeron® M 600/512K CPU onboard	0 ~ 60°C	-25 ~ 70°C
SBC84620	AMD LX embedded SBC with TTL LCD	0 ~ 60°C	-25 ~ 70°C
SBC84621	AMD LX embedded SBC with LVDS LCD	0 ~ 60°C	-25 ~ 70°C

Advantages

	Reliability: AXIOMTEK's fanless and extended temperature embedded solutions can improve system reliability and stability in critical temperature environments and more rigorous industrial applications.
	Applications: AXIOMTEK's eBOX series is suitable for a wide range of industrial applications in the market, such as POS, Kiosk, ATM, Thin Servers, diskless workstations, building automation, project screens for department stores and supermarkets, tour bus displays, and much more.
	Embedded OS: AXIOMTEK's series of fanless and extended temperature products can be bundled with embedded OS solutions: Microsoft Windows® and Embedded Linux family-based products and services including Windows® CE.NET, Windows® XP Embedded and Embedded Linux.
	Expansion: AXIOMTEK's fanless and extended temperature products support CompactFlash™ and 2.5" HDD drive bays.
	Watchdog Timer: the system will automatically reset to reduce the need for maintenance.
