| CPU |
- LGA1151 7th gen Intel® Core™ processor, TDP: 35 - 65W
- LGA1151 6th gen Intel® Core™ processor, TDP: 35 - 65W
|
| Chipset |
|
| System Memory |
- 2 x DDR4-1866/2133/2400 SO-DIMM, up to 32GB
|
| BIOS |
|
| COM |
- 2 x DB9 serial console or RS-232/422/485
|
| USB |
|
| PoE |
- Up to 16 x RJ-45/8 x RJ-45 & 8 x M12 PoE output max. 200W supports PoE & PoE+
- PoE (802.3af 15.4W/port)
- PoE+ (802.3at 30W/port)
|
| Ethernet |
- Flexible LAN selection:
- 8 x RJ-45 GbE LAN with 2 SATA (Intel® I210-AT)
- 8 x M12 A-coded GbE LAN with 4 SATA (Intel® I210-AT)
- 8 x RJ-45, 8 x M12 A-coded GbE LAN with 4 SATA (Intel® I210-AT)
- 16 x RJ-45 GbE LAN with 4 SATA or 2 SATA (Intel® I210-AT)
|
| Display |
- 1 x VGA (supports up to 1920 x 1200 @60Hz)
- 1 x DVI-D (supports up to 2K @60Hz)
- 1 x HDMI (supports up to 4K/2K @30Hz)
|
| CANbus |
|
| Digital I/O |
- 1 x Terminal block isolated 6-in/2-out DIO (isolation voltage: 2 kV)
|
| Audio |
|
| Storage |
- 2 x 2.5” 15 mm internal SATA drive with 2 SATA, Intel® RAID 0/1 supported
- 2 x 2.5” 15 mm swappable SATA drive with 2 SATA, Intel® RAID 0/1 supported
- 4 x 2.5” 15 mm swappable SATA drive with 4 SATA, Intel® RAID 0/1/5/10 supported
|
| Expansion |
- 2 x Full-size Rev.1.2 PCI Express Mini Card slot (USB/PCIe with external SIM socket)
- 1 x Half-size Rev.1.2 PCI Express Mini Card slot (mSATA/USB/PCIe)
- 1 x Half-size Rev.1.2 PCI Express Mini Card slot (USB)
|
| Others |
- 1 x Reset button
- 5 x Antenna opening
- 2 x External accessible SIM card socket
|
| Power Supply |
- General use: 1 x Terminal block, 9 to 36 VDC
- Vehicle: 1 x terminal block, 12/24 VDC with Smart ignition
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel, IP40
|
| Operating Temperature |
- -40°C to +70°C (-40°F to +158°F) with W.T. peripheral
|
| Relative Humidity |
- 0% to 95%, non-condensing
|
| Vibration |
- 3 Grms w/ SSD (5 to 500Hz, X/Y/Z direction; random, operating)
- 1 Grms w/ HDD (5 to 150Hz, X/Y/Z direction; random, operating)
- 2 Grms w/ HDD & Anti-Vibration Kit (5 to 500Hz, X/Y/Z direction; random, operating)
- MIL-STD-810G, Method 514.6C-VI Category 4 compliant
- EN 50155 EN (IEC) 61373 category 1 class B
|
| Shock |
- EN (IEC) 61373 category 1 class B, Half-sine pulse, 5g, 30ms (longitudinal direction), 3g, 30ms (vertical/transverse direction)
|
Dimensions
(W x D x H) |
- 2 internal SATA SKU: 280 x 210.5 x 70mm (11.02" x 8.27" x 2.76")
- 2 swappable SATA SKU: 280 x 210.5 x 83.7 mm (11.02” x 8.27” x 3.30”)
- 4 swappable SATA SKU: 280 x 210.5 x 99.2 mm (11.02” x 8.27” x 3.91”)
|
| Weight (net/gross) |
- 2 internal SATA SKU: 3.95 kg (8.71 lb)/4.97 kg (10.96 lb)
- 2 swappable SATA SKU: 4.92 kg (10.85 lb)/5.74 kg (12.65 lb)
- 4 swappable SATA SKU: 4.92 kg (10.85 lb)/5.74 kg (12.65 lb)
|
| Certifications |
- CE (Class A), FCC (Class A), E-Mark (E13) and EN 50155(1) and EN45545-2 certified
|
| EOS Support |
- Windows® 10 64-bit, Windows® 7 64/32-bit (for 6th gen Intel CPU), Linux
|
| Software Support |
|
| Mounting |
|
