CPU |
- 9th/8th gen Intel® Core™ processor, up to 65W
|
Chipset |
|
System Memory |
- 2 x DDR4-2666/2400 MT/s un-buffered SO-DIMM, up to 64GB
|
BIOS |
|
COM |
- 1 x RS-232/422/485 (default RS-232)
- More COM ports available from extension I/O modules
|
USB |
- Intel®H310:
- 4 x USB 3.1 Gen1
- 2 x USB 2.0
- 1 x USB 2.0 (internal, 180D type A for license key, up to 30mm)
- Intel®Q370:
- 4 x USB 3.1 Gen2
- 2 x USB 2.0
- 1 x USB 2.0 (internal, 180D type A for license key, up to 30mm)
- More USB ports available from extension I/O modules
|
Ethernet |
- 1 x 10/100/1000 Mbps Ethernet (Intel® I210-AT)
- 1 x 10/100/1000 Mbps Ethernet (Intel® I219-LM)
- More LAN ports available from extension I/O modules
|
Display |
|
Digital I/O |
- Available from extension I/O modules
|
Audio |
|
Storage |
- Intel® H310:
- 2 x 2.5" swappable HDD/SSD (7/9.5 mm height)
- Intel® Q370:
- 2 x 2.5" swappable HDD/SSD (7/9.5 mm height), supports RAID 0,1
- 1 x M.2 Key M 2280 socket (PCIe Gen3 x4) for NVMe SSD
|
Expansion |
- Intel® H310: 1 x Full-size PCI Express Mini Card slot (USB interface)
- Intel® Q370: 1 x Full-size PCI Express Mini Card slot (USB & PCIe interface) or 1 x M.2 Key B 3050 socket
- 1 x SIM slot
|
Others |
|
Power |
- Type: ATX/AT
- Input: 24 VDC (uMin=19V/uMax=30V)
|
Construction |
- Aluminum extrusion heavy-duty cold-rolled steel
|
Operating Temperature |
- -10°C to +60°C (+14°F to +140°F) with 9th/8th gen Intel® Core™ and W.T. HDD/SSD
|
Relative Humidity |
- 10% to 90%, non-condensing
|
Dimensions (W x H x D) |
- 83.5 x 192 x 230 mm (3.28" x 7.54" x 9.04")
|
Weight (net/gross) |
- 3.82 kg (8.43 lb)/4.78 kg (10.55 lb)
|
EOS Support |
|
Software Support |
|
Certifications |
- CE (EN 61000-6-4/EN 61000-6-2)
- FCC
|
