| CPU |
- Intel® Core™ i5-1335UE processor and Intel® processor U300E
|
| Chipset |
|
| System Memory |
- Dual DDR5-5200 SO-DIMM, up to 96GB
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec./min.
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 1G LAN (Intel® I219-LM)
- 1 x 2.5GbE LAN (Intel® I226-V)
|
| Display |
- 4 x HDMI 2.1 (TMDS)
- 4K@60Hz with cable lock design
|
| Audio |
|
| Storage |
- 1 x M.2 Key M 2280 slot (SATA & NVMe)
|
| Expansion |
- 1 x M.2 Key E 2230 for Wi-Fi/BT, support Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E (CNVi)
- 1 x M.2 Key B 3042 for 3G/4G/5G
- 1 x SIM slot
|
| Others |
- N/A
- 1 x power and reset button
- 1 x power LED
- 1 x Line-out
- 4 x antenna opening
|
| TPM |
|
| Power Supply |
- 1 x DC power input (lockable)
- +12V DC-in
|
| Vibration Endurance |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F), disabling CPU Turbo Boost (with W.T. DRAM & SSD, CPU TDP 15W)
|
Dimensions
(W x D x H) |
- 200 x 160 x 29 mm (7.8" x 6.2" x 1.14")
|
| Weight (net/gross) |
- 1.3 kg (2.86 lb)/2.3 kg (5.07 lb)
|
| Mounting |
|
| EOS Support |
|
| Software Support |
|
| Certifications |
|
