| CPU |
- 13th Gen Intel® Core™ i7/i5/i3 or processor U300E
|
| Chipset |
|
| System Memory |
|
| BIOS |
|
| Serial |
|
| USB |
- 2 x USB 3.2 Gen2
- 8 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps Ethernet (Intel® I226)
|
| Display |
- 1 x LVDS; 18/24-bit single channel (optional eDP 1.4b HBR3: 5120 x 3200 @ 60 Hz)
- 1 x DDI (with up to 8K supported)
|
| GPIO |
|
| Audio |
- HD link interface to baseboard for audio codec
|
| Storage |
- 2 x SATA 3.0
- NVMe for up to 512GB memory (optional)
|
| Expansion |
|
| Others |
|
| Battery |
|
| Power Input |
- ATX: +12V, +5VSB
- AT: +12V
- Extended voltage: 4.75V to 20V
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Extended Temperature: -40°C to +85°C (-40°F to +185°F)
- Standard Temperature: -20°C to +70°C (-4°F to 158°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
