| AI Accelerator |
- NVIDIA® Jetson Orin™ NX 16GB (157 TOPS)
- *Under planning: NVIDIA® Jetson Orin™ NX 8GB (117 TOPS), Orin™ Nano 8GB (67 TOPS) or Orin™ Nano 4GB (34 TOPS)
|
| CPU |
- NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3
|
| GPU |
- 1024-core NVIDIA Ampere GPU with 32 Tensor Cores
|
| Chipset |
|
| System Memory |
- 16GB 128-bit LPDDR5 onboard
|
| COM |
|
| USB |
- 1 x M12 A-Code 8-pos dual USB 2.0
|
| Ethernet/PoE |
- 2 x M12 X-Code 8-pos GbE PoE
- PSE, IEEE 802.3at, up to 30 watts of power
|
| Display |
|
| GMSL |
|
| Digital I/O |
- 1 x M12 A-Code 12-pos isolated 4-in/4-out DIO
|
| Audio |
|
| Storage |
- 1 x M.2 Key M 2280 with PCIe x4 NVMe SSD slot
|
| Expansion |
- 1 x full-size PCI Express Mini Card slot (USB + PCI Express signal) for Wi-Fi/LTE
- 1 x M.2 Key E 2230 slot for Wi-Fi 6E
- 1 x M.2 Key B 3042/3052 slot for 5G/LTE
- 1 x Nano SIM slot
|
| Others |
- 5 x N-Jack antenna opening with a waterproof design
|
| Power Supply |
- 1 x M12 A-Code 5-pos power input
- Input: 9 to 36 VDC (typical 12/24 VDC)
- Inrush current: 0.69A/3.08A
|
| Watchdog Timer |
|
| Construction |
- Aluminum die-casting and heavy-duty steel, IP67
|
| Operating Temperature |
- 25W power mode: -25°C to +60°C (-13°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
- IEC 60068-2-64 (with SSD: 3Grms STD, random, 5 to 500 Hz, 1 hr/axis)
|
| Shock |
- IEC 60068-2-27 (with SSD: 50G, half-sine, 11 ms duration)
|
| Dimensions (W x D x H) |
- 240 x 220 x 93.4 mm (9.44" x 8.66" x 3.67")
|
| Weight (net/gross) |
- 4 kg (8.81 lb)/7.2 kg (15.87 lb)
|
| Certifications |
|
| EOS Support |
- Linux Ubuntu 22.04 or later
|
| Mounting |
|
