| CPU |
- LGA1851 socket 15th Gen Intel® Core™ Ultra 9/7/5 processors, up to 125W (Arrow Lake-S)
|
| Chipset |
|
| System Memory |
- 4 x 288-pin DDR5-4400 ECC/non-ECC un-buffered Long-DIMM, up to 192GB (ECC memory available only for Intel® W880)
|
| BIOS |
|
| COM |
- 2 x RS-232 (internal box header)
- 2 x RS-232/422/485 (internal box header)
|
| USB |
- 4 x USB 3.2 Gen 2x1 (10G) & 4 x USB 3.2 Gen 1x1 (5G) (rear I/O)
- 2 x Dual USB 3.2 Gen 1x1 (5G) (internal, box header)
- 1 x USB 2.0 (internal, 180D Type-A)
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I219-LM, Intel® AMT with Intel vPro®)
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I226-V)
- 1 x 10/100/1000Mbps IPMI LNA (Intel® I210-AT shared with AST2600) (optional)
|
| Display |
- 1 x HDMI 1.4b, up to 4096 x 2160 @ 24Hz
- 1 x Displayport++ (DP 1.2), up to 4096 x 2304 @ 60Hz
|
| Digital I/O |
|
| Audio |
|
| Storage |
- 4 x SATA-600 with RAID 0/1/5/10
- 2 x M.2 key M 2280 in support of PCIe x4 via CPU with RAID 0/1
|
| Expansion |
- 2 x PCIe Gen 5 x16 slots (signal: PCIe x16 + PCIe x0 or PCIe x8 + PCIe x8)
- 5 x PCIe x4 slot open ended 3 x PCIe x4 signal, slot 3 & 6 PCIe x2 signal (signal by PCH)
|
| Others |
- IPMI 2.0 supported by OpenBMC
- 1 x PS/2 keyboard (rear I/O)
- 1 x PS/2 mouse (rear I/O)
|
| Battery |
|
| TPM |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
