| CPU |
- LGA1700 socket 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor (up to 125W)
|
| Chipset |
|
| System Memory |
- 4 x 288-pin DDR5-4400 non-ECC Long-DIMM, up to 192GB
|
| BIOS |
|
| COM |
- 1 x RS-232 (rear I/O)
- 3 x RS-232 (internal box header)
- 1 x RS-232/422/485 (internal box header)
- 1 x RS-232/485 (internal box header)
|
| USB |
- 6 x USB 3.2 Gen1x1 (5Gbps, rear I/O)
- 2 x USB 3.2 Gen1x1 (5Gbps, internal box header)
- 4 x USB 2.0 (internal pin header)
- 1 x USB 2.0 (internal 180D Type-A)
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I210-AT)
- 1 x 10/100/1000 Mbps (Intel® I219-V)
|
| Display |
- 1 x VGA, up to 1920 x 1200 @ 60Hz
- 1 x HDMI 2.0, up to 4096 x 2160 @ 60Hz
- 1 x DVI-D, up to 1920 × 1200 @ 60Hz
|
| Digital I/O |
|
| Audio |
- HD Codec audio as MIC-in/Line-in/Line-out
|
| Storage |
- M.2 Key M 2280 with support for PCIe x4 via CPU
- 4 x SATA-600 with RAID 0/1/5/10
|
| Expansion |
- 2 x PCIe x16 slot (signal: PCIe Gen4 x16 + PCIe Gen3 x4)
- 3 x Open-ended PCIe Gen4 x4 slot
- 1 x M.2 Key E 2230 (supports PCIe x1 + USB 2.0)
- 2 x 32-bit PCI slot; default clock is 33 MHz
|
| Others |
- 1 x PS/2 keyboard (rear I/O)
|
| Battery |
|
| TPM |
- Not included by default; supports Intel® PTT as default
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
