| CPU |
- LGA1151 socket 9th/8th gen Intel® Core™ i7/i5/i3, Xeon® E, Pentium® or Celeron® processor (up to 95W)
|
| Chipset |
|
| System Memory |
- 4 x 288-pin DDR4-2666/2400 ECC DIMM, up to 128GB (Intel® Core™ i7/i5 only support non-ECC)
|
| BIOS |
|
| COM |
- 4 x RS-232 (Internal box header)
- 2 x RS-232/422/485 (1 rear I/O; 1 internal box header)
|
| USB |
- 2 x USB 3.2 Gen 2x1 (10Gbps) (rear I/O)
- 4 x USB 3.2 Gen 2x1 (5Gbps) (rear I/O, internal box header)
- 7 x USB 2.0 (pin header, 180D type A)
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I219-LM, AMT)
- 1 x 10/100/1000 Mbps (Intel® I210-AT)
|
| Display |
- 1 x VGA
- 1 x DVI-D
- 1 x HDMI
- 1 x DisplayPort++
|
| Digital I/O |
|
| Audio |
- HD Codec audio as MIC-in/Line-in/Line-out with Realtek ALC888
|
| Storage |
- 5 x SATA-600 with RAID 0/1/5/10
|
| Expansion |
- 1 x PCIe x16 slot
- 2 x PCIe x4 slot
- 4 x PCI slot
- 1 x PCIe Mini Card slot with PCIe x1, USB 2.0 & SATA
|
| Others |
- 1 x PS/2 keyboard and mouse
- SMBus
|
| Battery |
|
| TPM |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
