| CPU |
- 11th gen Intel® Core™ i5/i3 or Celeron® processor (Tiger Lake)
|
| Chipset |
|
| System Memory |
- 2 x DDR4-3200 SO-DIMM, max. up to 64GB
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec./min.
|
| COM |
|
| USB |
- 3 x USB 3.2 Gen 2
- 1 x USB 2.0
|
| Ethernet |
|
| Display |
|
| Audio |
|
| Storage |
- 1x M.2 Key M 2280 (SATA & NVMe)
|
| Expansion |
- 1 x M.2 Key E 2230 for Wi-Fi/Bluetooth
- 1 x M.2 Key B 3052 for 5G/LTE
- 1 x SIM card slot
|
| Others |
- 1 x Device management
- 1 x DC power input (lockable)
- 1 x HDD LED
- 1 x Power switch
- 1 x Reset switch
- 6 x Antenna opening
- 1 x Remote power switch
|
| TPM |
|
| Power Supply |
|
| Vibration Endurance |
|
| Operating Temperature |
- 0ºC to +50ºC (+32ºF to +122ºF)
|
Dimensions
(W x D x H) |
- 260 mm (10.24") (W) x 160 mm (6.3") (D) x 25 mm (0.99") (H)
|
| Weight (net/gross) |
- 1.3kg (2.86 lb)/2.07kg (4.6 lb)
|
| Mounting |
|
| EOS Support |
|
| Software Support |
- Remote Device Management (RDM)
|
| Certifications |
|
