| CPU |
- Dual socket FCLGA4677 for 4th Generation Intel® Xeon® Scalable processors
|
| Chipset |
- Intel® C741, TDP 11W
- BMC: ASpeed AST2600
|
| System Memory |
- 16 x DDR5-4800 ECC RDIMM, up to 512GB
|
| Graphics |
|
| BIOS |
|
| Remote Management |
- IPMI 2.0 supported by OpenBMC
|
| COM |
|
| USB |
- 4 x USB 3.0
- 1 x USB 3.0 type C
|
| Ethernet |
- 1 x Network card supports dual 10G Base-T
- 1 x IPMI 1 GbE LAN
|
| Storage |
- 6 x 2.5" SATA SSD swappable slot; support RAID 0,1,5,10
- 2 x 2.5" U.3 SSD swappable slot; support RAID 0,1,5,10
|
| Display |
- 1 x DisplayPort 1.1a (2560x1600)
|
| Expansion |
- 2 PCIe riser cards inside:
- Riser Card #0: 2 x PCIe x16 Gen 5.0 slot
- Riser Card #1: 2 x PCIe x16 Gen 5.0 slot
- 1 x M.2 Key M 2280 slot, with PCIe x4 (NVMe)
|
| Others |
- 1 x Green LED for system power-on
- 1 x Green LED for SSD active
- 1 x Green/Orange LED for system health status
|
| Power Supply |
- 2 x 1600W redundant ATX power supply
|
| Watchdog Timer |
- Reset: 1 to 65535 sec./min. and 1 sec. or 1 min./step
|
| Operating Temperature |
- 0°C to +40°C (32°F to +104°F)
|
| Relative Humidity |
- 10% - 95%, non-condensing
|
| Vibration Endurance |
|
| Dimensions (W x D x H) |
- 430 x 700 x 88 mm (19” x 27.5” x 3.5”)
|
| Weight (net/gross) |
|
| EOS Support |
|
| Certifications |
|
