| CPU |
- Intel® Atom® processor E3845 1.91GHz quad core onboard (Bay Trail)
|
| Chipset |
|
| System Memory |
- 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8 GB
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® i211AT)
|
| Display |
|
| Digital I/O |
|
| Audio |
|
| Storage |
|
| Expansion |
- 1 x Full-size PCI Express Mini Card slot with mSATA
- 1 x Half-size PCI Express Mini Card slot
|
| Others |
- SMbus
- ST ST33TPM12LPC with TPM 1.2 compliant
|
| Battery |
|
| Power Input |
- 1 x 4-pin connector
- +12V DC-in only
- AT Auto Power On function supported
|
| Power Requirements |
- Intel® Atom® E3845 @ 1.91 GHz, 8GB DDR3L
Max. RMS: +12V @ 1.49A
|
| Watchdog Timer |
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C ~ +70°C (-4°F ~ +158°F)
|
| Relative Humidity |
- 10% ~ 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
| Industrial Chassis |
|
