| CPU |
- 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor, up to 65W (Kaby Lake/Skylake)
|
| Chipset |
|
| System Memory |
- 2 x SO-DIMM DDR4-2133/2400, up to 32GB
|
| BIOS |
|
| COM |
- Available from extension I/O modules
|
| USB |
- 4 x USB 3.0
- More USB ports available from extension I/O modules
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I210-AT)
- More LAN ports available from extension I/O modules
|
| Display |
|
| Digital I/O |
- Available from extension I/O modules
|
| Audio |
- 1 x Audio (Mic-in/Line-out)
|
| Storage |
- 2 x 2.5" swappable HDD (15 mm height)
|
| Expansion |
- AX96205: 1 PCIe x16 + 1 PCIe x4
- AX96206: 1 PCIe x16 + 1 PCI
- AX96207: 2 PCI
- 1 x Full-size PCI Express Mini Card slot with USB interface
|
| Others |
- 1 x Switch for power on/off (ATX)
- 1 x Remote switch
- 1 x Reset switch
- 1 x 3-pin terminal block
- 1 x AT/ATX selectable switch
- TPM 2.0
|
| Power |
- Type: ATX/AT
- Input: 24VDC (uMin=19V/uMax=30V)
|
| Construction |
- Aluminum extrusion heavy-duty cold-rolled steel
|
| Operating Temperature |
- -10°C to +60°C (+14°F to +140°F) with 6th gen Intel® Core™ up to 35W and W.T. HDD/SSD
- -10°C to +50°C (+14°F to +122°F) with 6th/7th gen Intel® Core™ up to 65W and W.T. HDD/SSD
|
| Relative Humidity |
- 10% to 90%, non-condensing
|
Dimensions
(W x H x D) |
- 147.5 x 192 x 230 mm (5.80" x 7.54" x 9.04")
|
| Weight (net/gross) |
- 4.382 kg (9.66 lb)/5.346 kg (11.80 lb)
|
| Software Support |
|
| EOS Support |
|
| Certifications |
|
